Hien Lub VigorLife Series Cov Cuab Yeej Cuab Yeej Cuab Yeej Zoo Tshaj Plaws -30 ℃ Cov Cuab Yeej Siv Hluav Taws Xob thiab Cov Cuab Yeej Cuab Yeej 16kW–38kW Featured Duab

Hien Lub VigorLife Series Cov Cuab Yeej Cuab Yeej Cuab Yeej Zoo Tshaj Plaws -30 ℃ Cov Cuab Yeej Siv Hluav Taws Xob thiab Cov Cua Txias Txias 16kW-38kW

Lus piav qhia luv luv:

Dual Functionality: Cua sov thiab txias muaj peev xwm.
Cua sov muaj peev xwm: 16-38kW.
Advanced Compression Technology: DC inverter teb EVI compressor
Kev khiav hauj lwm kub ntau yam: Cua sov -30 ℃ to 28 ℃, Txias 15 ℃ to 50 ℃
Kev Nyab Xeeb Kev Nyab Xeeb Kev Nyab Xeeb: Kev ua haujlwm ruaj khov hauv -30 ℃ ib puag ncig.
Smart Controls: Wi-Fi enabled nrog app rau kev tswj chaw taws teeb yooj yim.
Txhim khu kev tiv thaiv khov: Nta 8 txheej ntawm kev tiv thaiv khov.
Kev Ua Haujlwm Dav Dav: Ultra-wide voltage kev khiav hauj lwm ntau ntawm 285V txog 460V.
Kev ua haujlwm ntsiag to: Tsim kom muaj suab nrov tsawg.
Ntse Defrost Technology: Frost-dawb ua haujlwm.
Eco-Friendly: Siv R32 refrigerant.
Qhov siab tshaj plaws cua kub dej qhov hluav taws xob: 55 ℃.
Yam tsawg kawg nkaus dej txias qhov hluav taws xob kub: 5 ℃.

Xa email rau peb

Download tau li PDF

Product Detail

Khoom cim npe

Lub tshuab nqus tsev twj tso kua mis (1)

Dual Functionality: Cua sov thiab txias muaj peev xwm.
Cua sov muaj peev xwm: 16-38 kW.
Advanced Compression Technology: DC inverter teb EVI compressor
Kev khiav hauj lwm kub ntau yam: Cua sov -30 ℃ to 28 ℃, Txias 15 ℃ to 50 ℃
Kev Nyab Xeeb Kev Nyab Xeeb Kev Nyab Xeeb: Kev ua haujlwm ruaj khov hauv -30 ℃ ib puag ncig.
Smart Controls: Wi-Fi enabled nrog app rau kev tswj chaw taws teeb yooj yim.
Txhim khu kev tiv thaiv khov: Nta 8 txheej ntawm kev tiv thaiv khov.
Kev Ua Haujlwm Dav Dav: Ultra-wide voltage kev khiav hauj lwm ntau ntawm 285V txog 460V.
Kev ua haujlwm ntsiag to: Tsim kom muaj suab nrov tsawg.
Ntse Defrost Technology: Frost-dawb ua haujlwm.
Eco-Friendly: Siv R32 refrigerant.
Qhov siab tshaj plaws cua kub dej qhov hluav taws xob: 55 ℃.
Yam tsawg kawg nkaus dej txias qhov hluav taws xob kub: 5 ℃.

WIDE VOLTAGE ua haujlwm ntau yam

Hien Air Source Heat Pumps ua haujlwm ruaj khov nyob rau hauv 285-460 V, tsim los xyuas kom muaj kev siv ib txwm siv txawm tias nyob hauv cheeb tsam uas muaj qhov cuam tshuam loj heev.

Lub tshuab nqus tsev twj tso kua mis (2)

Wider Ambient Kub Ua Haujlwm Ntau Yam:

Cua sov -30 ℃ to 28 ℃; Txias 15 ℃ to 50 ℃.

Qhov siab tshaj plaws cua kub dej qhov hluav taws xob: 55 ℃. Yam tsawg kawg nkaus dej txias qhov hluav taws xob kub: 5 ℃.

Lub tshuab nqus tsev twj tso kua mis (3)

Lub npe		DLRK-28 II BA/A1	DLRK-31 II BA/A1	DLRK-33 II BA/A1	DLRK-38 IIBA/A1
Fais fab mov		380V 3N ~ 50Hz	380V 3N ~ 50Hz	380V 3N ~ 50Hz	380V 3N ~ 50Hz
Anti-Electric Shock Rate		Chav kawm I	Chav kawm I	Chav kawm I	Chav kawm I
Ingress Protection Rating		IPX4	IPX4	IPX4	IPX4
Qhov xwm txheej 1	Rated Cua Txias Muaj Peev Xwm	12500W ~ 28000W	13000W ~ 31000W	13500W ~ 33000W	15000W ~ 38000W
Chav tsev hom		Pem teb cua sov hom(Qhov hluav taws xob Dej Temp.35 ℃)
Qhov xwm txheej 2	Rated Cua Txias Muaj Peev Xwm	21 000 W	23 000 W	24600 wb	28200 wb
	Rated Heating Power Input	7500 W	7900 wb	8800 wb	9700 wb
	Cua sov COP	2.80 Nws	2.91 ib	2.80 Nws	2.91 ib
Qhov xwm txheej 4	Tsawg Temp. Lub peev xwm cua sov	17800 wb	19200 wb	20600 wb	23 500 W
	Low Ambient Heating Power Input	7250 wb	7600 wb	8400 wb	9300 wb
	Low Ambient COP	2.46 ib	2.53 ib	2.45 Nws	2.53 ib
HSPF		3.90 ib	3.90 ib	3.80 ib	3.80 ib
Chav tsev hom		Ntxuam Coil Unit Hom(Qhov hluav taws xob Dej Temp.41 ℃)
Qhov xwm txheej 2	Rated Cua Txias Muaj Peev Xwm	21 000 W	23 000 W	24600 wb	28200 wb
	Rated Heating Power Input	8250 wb	8700 wb	9600 wb	10 700 W
	Cua sov COP	2.55 Nws	2.64 ib	2.56 ib	2.64 ib
Qhov xwm txheej 4	Tsawg Temp. Lub peev xwm cua sov	17800 wb	19200 wb	20600 wb	23 500 W
	Low Ambient Heating Power Input	8000 W	8300 wb	9100 wb	10200 W
	Low Ambient COP	2.23	2.31 Nws	2.26	2.30 Nws
HSPF		3.40 Nws	3.50 Nws	3.40 Nws	3.40 Nws
APF		3.45 Nws	3.55 Nws	3.45 Nws	3.45 Nws
	Chav tsev hom	Hom Radiator(Qhov hluav taws xob Dej Temp.50 ℃)
Qhov xwm txheej 2	Rated Cua Txias Muaj Peev Xwm	21 000 W	23 000 W	24600 wb	28200 wb
	Rated Heating Power Input	9500 wb	9900 wb	11000 W	12 100 W
	Cua sov COP	2.21	2.32 ib	2.24	2.33 ib
Qhov xwm txheej 4	Tsawg Temp. Lub peev xwm cua sov	17800 wb	19200 wb	20600 wb	23 500 W
	Low Ambient Heating Power Input	9200 wb	9400 wb	10400 W	11 400 W
	Low Ambient COP	1.93 ib	2.04 Nws	1.98 ib	2.06 Nws
HSPF		2.80 Nws	2.95 ib	2.85 ib	2.85 ib
Rated Dej Flow		4.13 m³ / h	4.47 m³ / h	4.82 m³ / h	5.33 m³ / h
Qhov xwm txheej 3	Rated Txias Capacity	24 000 W	26 000 W	28 000 W	31 000 W
	Lub zog nkag	8200 wb	8600 wb	10000 W	11000 W
	EER	2.93 ib	3.02 Nws	2.80 Nws	2.82 ib
CSPF		4.92 ib	4.65 ib	4.50 Nws	4.52 ib
Max Fais fab Input		11 200 W	12500 W	13500 W	15 800 W
Max khiav tam sim no		21.5a ua	24 A	26 A	30 A
Dej Siab poob		35kp ua	30kp ua	35kp ua	35kp ua
Max Siab ntawm Siab / Tsawg Siab Sab		4.3 / 4.3 Mpa	4.3 / 4.3 Mpa	4.3 / 4.3 Mpa	4.3 / 4.3 Mpa
Tso cai tso tawm / Sucion Siab		4.3 / 1.2Mpa	4.3 / 1.2Mpa	4.3 / 1.2Mpa	4.3 / 1.2Mpa
Max siab ntawm evaporator		4.3Mpa	4.3Mpa	4.3Mpa	4.3Mpa
Kev sib txuas ntawm cov kav dej		DN32/1¼ " Poj niam Xov
Suab nrov		58.5dB (A)	59dB (A)	59.5dB (A)	60dB (A)
Refrigerant / Charge		R32/3.6kg	R32/4.0kg	R32/4.0kg	R32/4.8kg
Qhov Loj (LxWxH) (mm)		1100x440x1520	1100x440x1520	1100x440x1520	1200x430x1550
Net nyhav		153kg ua	162kg ua	162kg ua	182kg ua

Condition 1: Sab nraum zoov Cua Temp. : DB 7°C / WB 6°C , Qhov hluav taws xob Dej Temp.45 ℃
Condition 2: Sab nraum zoov Cua Temp. : DB -12°C / WB -13.5°C
Condition 3: Sab nraum zoov Cua Temp. : DB 35 ° C /-, Qhov hluav taws xob dej kub.7 ℃
Condition 4: Sab nraum zoov Cua Temp. Kub: DB -20 ° C /-
